Minelab Equinox Tips and Settings

Neil’s U.K. Winkler Extreme 50 Tones

This is another great Minelab Equinox setting. You have to respect the amount of work it takes to find anything in England’s centuries worth of iron.   Neil and IHG have done a ton of research and testing of the EQ and CTX to develop systems for these conditions.  If you want to hunt iron infested sites these are the guys to learn from.

Only use this is you are very competent and know the Equinox very well as I assure you if you don’t you will soon change it back to what you had before. In iron infested hotspots swing very slow and low just skimming the surface if possible.


SENSITIVITY – 25 Full, but if you can’t handle the noise lower it but no lower than 19.

50 TONES – long press and put T1 to 1 and T2 to 10 this gives the iron the lowest tone and makes the non-ferrous and medium tones lower than they normally are but still gives sweet non- ferrous high tones.

VOLUME – 25 Long press and put T1 to 1 and T2 to 25 this gives the iron a nice low volume in the background and full volume on the non-ferrous tones.

THRESHOLD – 6 which is fine for my ears but I don’t know about yours, then long press and put pt to 1 this gives the threshold hum the lowest tone it can go to which is more pleasant.

√/× long press and put to 1, having it on 2 or higher can miss you some choice finds so beware!!

DETECTOR SPEED for general searching I have it set at 5 but once I hit a hotspot I have it set on 1 as like I said in the thread if the detector is swung slow n low scraping the surface it does a perfect job of separating in between iron and for me it makes those really faint dodgy tone’s stand out a tiny bit more while also giving better depth even in heavy iron. Also because it’s on number 1 unless the finds are on or near the surface the beeps are wider apart so just another thing that can be hard to get used to.

IRON BIAS – 0 I like to suck all the non-ferrous I can between the iron, etc. But if you can’t get to grips with it put iron bias on 1, 2 or 3.

ALL METAL – full black horseshoe as I like to hear everything and its what does give you an edge.


GROUND BALANCE – 1 for general searching because that’s where it settles on iron ferrite, when you hit a hotspot I ground balance manually but beware as it is noisier and why I don’t tell everybody to ground balance unless they are well competent with the machine.

Last year: About 2/3rds with the Equinox. Be sure to check out the reviews for my 3 book titles on this great detector!  Link below.


 Reviews: “The Minelab Equinox: From Beginner to Advanced”

“..after reading the beginner to advanced guide book my finds have doubled, best book for the money.”


“Received the book. Excellent information within! Great for beginning with the Nox, as well as advanced settings and techniques for experienced users.
Great reference that I will refer to often. Very in-depth on the capabilities and functions of the Equinox line. Pleased with this purchase!! Recommended for all Equinox users, and potential buyers.”

“After reading your book I concentrated much more on the sound quality of targets. I very quickly started to understand which sounds to dig. Have found several ancient coins already.”

“This is the book that started me swinging my nox 8oo with great satisfaction.”
“Just bought this book. Feel like I’ve only been getting about 25% out of my machine… thanks for this post.”

Neil Jones U.K “Beach for Land” Settings

“Beach 1” (As shown earlier this can also be used in “Beach 2” as a more stable “50 Tone” “checker” for salt water or black sand.  This gives even more iron rejection as well).

Frequency: Multi

Sensitivity: “18” to “25”

Volume: “25”

Tone Volume: T1=1, T2 = 25

Threshold: “4”

Threshold Pitch (800 Model): “1”

Target Tones: “50”

Tone Pitch: T1 = “1” T2 = “20”

Accept / Reject = “-9” to “0”

Tone Break: “1” (bringing this up to  “2” is a good way to get more depth running “Beach 2” in salt).

Recovery Speed: “2” to “5”

Iron Bias: “5”

All Metal (“Horseshoe” Mode) ON.

While this program is quite highly regarded as a dense iron set-up–remember that it’s developed for U.K conditions where they are trying to bring up bronze, brass and copper targets.  These are the “blended with the ground” objects that respond best to these slow Recovery Speeds.  The slowed Recovery Speed may bring up targets in dense iron but there are also “nail board” type videos online showing this system missing part-masked signals that faster relic programs hit well.

Also, this set up is designed for the U.K context.  If you want to not dig so much copper cents and more silver–running a “5 Tone” checker opposite Neils’ program is not a bad idea.
